PSV Series(Closed circuit)

Model, Displacement(cm³/rev), Max/ working pressure(Mpa), Max. speed(rpm), Control device control(N·m)
PSVD2-17E,16.8⨉2,24,"2,550","Horsepower control"
PSVD221E,20.8⨉2,24,2400," "
PSVD2-27E,26.9⨉2,24,2400," "
PSVD2-42,42.3⨉2,32,2200," "

The direction of rotation of the input shaft is to be set in one direction.
Please specify either "CW" or "CCW" as the direction of rotation.

PSVD Series(Open circuit)

Model, Displacement(cm³/rev), Max/ working pressure(Mpa), Max. speed(rpm), Control device control(N·m)
PSVL-42,42,24.5,2500,"Hosrpose Control, Load-sensing control"
PSVL-42,64,24.5,2400," "
PSVL-84,84.6,32,2200," "

Only CW is available (clockwise when viewing from the input shaft side).

PSVL Series(Open circuit and load sensing)

Model, Displacement(cm³/rev), Max/ working pressure(Mpa), Max. speed(rpm), Typical Input horsepower(kw)
PSV-10,10.0,27.5,3600,8
PSV-16,16.4,27.5,3600,13.2
PSV2-10,10.0⨉2,27.5,3200,7⨉2
PSV2-16,16.4⨉2,27.5,3200,11.7⨉2
PSVH2-28,28.1⨉2,34.3,3000,23.⨉2

Load sensing type variable displacement pump
Use together with a load-sensing (LS) valve. (See Page 49.)
Only CW type is available (clockwise when viewing from the input shaft side).
